Overview

Each step in a Jinba Flow can be configured with advanced options that control how and when it executes. These options allow you to create sophisticated workflows with conditional logic, loops, and complex dependencies.

​
Step Dependencies (needs)

The needs option specifies which steps must complete before the current step can run. This creates an execution order and ensures data is available when needed.

​
Basic Usage

- id: analyze_data
  tool: PYTHON_SANDBOX_RUN
  needs:
    - fetch_data
    - validate_input
  input:
    - name: code
      value: "process({{steps.fetch_data.result}})"

​
Key Points

  • Execution Order: Steps with needs wait for all specified dependencies to complete
  • Parallel Execution: Steps without dependencies run in parallel automatically
  • Failure Handling: If a dependency fails or is skipped, dependent steps are also skipped
  • Diamond Patterns: Complex dependency graphs are supported (A→B, A→C, B→D, C→D)

​
Example: Multi-Branch Workflow

- id: input_data
  tool: INPUT_JSON
  input:
    - name: value
      value: "[1, 2, 3, 4, 5]"

- id: process_even
  tool: PYTHON_SANDBOX_RUN
  needs:
    - input_data
  input:
    - name: code
      value: |
        data = {{steps.input_data.result}}
        result = [x for x in data if x % 2 == 0]

- id: process_odd
  tool: PYTHON_SANDBOX_RUN
  needs:
    - input_data
  input:
    - name: code
      value: |
        data = {{steps.input_data.result}}
        result = [x for x in data if x % 2 != 0]

- id: combine_results
  tool: PYTHON_SANDBOX_RUN
  needs:
    - process_even
    - process_odd
  input:
    - name: code
      value: |
        even = {{steps.process_even.result}}
        odd = {{steps.process_odd.result}}
        result = {"even": even, "odd": odd}

​
Conditional Execution (when)

The when option allows a step to execute only if a specified condition is true. This enables dynamic workflow behavior based on previous step results.

​
Basic Syntax

- id: conditional_step
  tool: TOOL_NAME
  when: "<condition_expression>"
  input:
    - name: param
      value: "value"

​
Condition Expressions

Conditions support:
  • String Comparison: "{{steps.check.result.status}}" == "success"
  • Numeric Comparison: {{steps.count.result}} > 5
  • Boolean Evaluation: {{steps.validate.result.isValid}} == true

​
Example: Conditional Branching

- id: check_type
  tool: PYTHON_SANDBOX_RUN
  input:
    - name: code
      value: |
        result = {"type": "premium"}

- id: premium_processing
  tool: PYTHON_SANDBOX_RUN
  when: "'{{steps.check_type.result.type}}' == 'premium'"
  needs:
    - check_type
  input:
    - name: code
      value: |
        result = "Processing premium user..."

- id: standard_processing
  tool: PYTHON_SANDBOX_RUN
  when: "'{{steps.check_type.result.type}}' == 'standard'"
  needs:
    - check_type
  input:
    - name: code
      value: |
        result = "Processing standard user..."

​
Important Notes

  • Conditions are evaluated before step execution
  • If the condition is false, the step status becomes skipped
  • Skipped steps don’t affect downstream steps that depend on them (they will also be skipped)
  • Use single quotes around template variables in string comparisons

​
Loop Execution (forEach)

The forEach option executes a step multiple times, once for each item in a collection. This is useful for batch processing lists of data.

​
Basic Syntax

- id: process_items
  tool: TOOL_NAME
  forEach: "{{steps.get_list.result}}"
  input:
    - name: item
      value: "{{item}}"

​
How It Works

  1. The forEach value is evaluated to get a list/array
  2. The step executes once for each item in the list
  3. Inside the step, {{item}} refers to the current item
  4. Results are collected as an array

​
Example: Processing Multiple Items

- id: get_users
  tool: INPUT_JSON
  input:
    - name: value
      value: |
        [
          {"id": 1, "name": "Alice"},
          {"id": 2, "name": "Bob"},
          {"id": 3, "name": "Charlie"}
        ]

- id: greet_users
  tool: PYTHON_SANDBOX_RUN
  forEach: "{{steps.get_users.result}}"
  needs:
    - get_users
  input:
    - name: code
      value: |
        user = {{item}}
        result = f"Hello, {user['name']}!"

- id: combine_greetings
  tool: PYTHON_SANDBOX_RUN
  needs:
    - greet_users
  input:
    - name: code
      value: |
        greetings = {{steps.greet_users.result}}
        result = "\n".join([g['result'] for g in greetings])

​
Accessing Item Properties

forEach: "{{steps.items.result}}"
input:
  - name: id
    value: "{{item.id}}"
  - name: name
    value: "{{item.name}}"

​
forEach with Index

If you need the index of the current item, you can use Jinja2 loops in the input:
- id: process_with_index
  tool: PYTHON_SANDBOX_RUN
  input:
    - name: code
      value: |
        items = {{steps.get_items.result}}
        results = []
        {%- for item in items %}
        results.append({"index": {{loop.index}}, "value": "{{item}}"})
        {%- endfor %}
        result = results

​
Combining Options

You can combine needs, when, and forEach in a single step:
- id: process_active_items
  tool: PYTHON_SANDBOX_RUN
  needs:
    - get_items
    - check_enabled
  when: "{{steps.check_enabled.result.active}} == true"
  forEach: "{{steps.get_items.result}}"
  input:
    - name: code
      value: |
        item = {{item}}
        result = f"Processed: {item}"
Evaluation Order:
  1. Wait for all needs dependencies to complete
  2. Check if when condition is true
  3. If true, execute forEach loop (or single execution if no forEach)

​
Best Practices

​
Dependencies

  • Keep dependency chains shallow when possible
  • Use parallel execution to improve performance
  • Clearly name steps to make dependencies readable

​
Conditions

  • Use meaningful condition expressions
  • Consider all possible outcomes (success, failure, edge cases)
  • Test conditions with various input values

​
Loops

  • Limit loop iterations to avoid long execution times
  • Handle empty arrays gracefully
  • Consider memory usage for large datasets
